UYANG BELTING Conveyor Belts for the Wood Industry
As a leading brand in the conveyor belt industry, UYANG BELTING offers high-performance, durable conveyor belt solutions tailored to meet the demands of the woodworking sector. Our conveyor belts are specifically designed to withstand the rigorous conditions of wood processing, furniture manufacturing, and finished product handling, ensuring efficient and reliable operations throughout the production line.
Here are the key advantages of UYANG BELTING conveyor belts in the wood industry:
High Wear and Impact Resistance: Wood processing requires conveyor belts with excellent wear resistance due to the abrasive nature of the operations, such as cutting, grinding, and sanding. UYANG BELTING conveyor belts are made from high-quality materials that provide superior wear resistance and can endure mechanical impacts, ensuring long service life even under harsh conditions.
Tear Resistance and High Load Capacity: Woodworking processes often involve transporting heavy timber and machinery, placing significant stress on conveyor belts. UYANG BELTING conveyor belts are designed with exceptional tear resistance and can handle heavy loads, ensuring stable transportation of wood without the risk of breakage or downtime.
Heat and Oil Resistance: The woodworking industry frequently involves high-temperature environments and the use of oils or finishes. UYANG BELTING conveyor belts offer excellent heat resistance and can withstand exposure to oils and chemicals used in wood treatment, maintaining performance and extending belt life.
Smooth Transport and Precision Control: Precision and smooth transportation are essential for woodworking machinery to ensure accurate positioning of wood for processing. UYANG BELTING provides conveyor belt solutions with high precision control, enhancing production efficiency and ensuring high-quality output in wood products.
Custom Solutions: UYANG BELTING understands the diverse requirements of woodworking processes. We offer custom-designed conveyor belts with special features like guide strips, sidewalls, and cleats to accommodate various wood handling applications, optimizing the production process.
UYANG BELTING is committed to providing the wood industry with high-performance conveyor belt products that enhance productivity while reducing maintenance costs. With our extensive experience and innovative technology, UYANG BELTING has become a trusted partner in the wood industry.
Here are the key items of UYANG BELTING conveyor belts in the wood industry:
Technical Data for Wood Processing Industry Belt | ||||||||||||
type | color | thickness | covering thickness | pattern | PLY | weight | Effective pull at 1% elongation (N/mm) | Breaking strength (N/mm) | Min Dia of pulley (mm) | Counter flexion (mm) | Tempeature (℃) | Application |
70P22-46/28 | Grey | 7.0mm | 5.0mm | Capsule stud | 2 plies | 6Kg/㎡ | 10N/mm | 180 N/mm | 80mm | 120 mm | -15/80℃ | wood processing |
90P32-36/28 | Black | 9.0mm | 6.0mm | Capsule stud | 3 plies | 8.4 Kg/㎡ | 22 N/mm | 270 N/mm | 120mm | 200 mm | -20/80℃ | wood processing |
90P32-36/13 | Black | 9.0mm | 6.0mm | Square | 3 plies | 8.0Kg/㎡ | 22N/mm | 270 N/mm | 120mm | 200 mm | -15/80℃ | wood processing |
90P32-46/43 | Grey | 9.0mm | 6.0mm | Grinding square | 3 plies | 8.1Kg/㎡ | 22N/mm | 270 N/mm | 100mm | 150 mm | -20/80℃ | wood processing |
50P22-16/3A | Green | 5.0mm | 3.5mm | Rough top | 2 plies | 4.7Kg/㎡ | 10N/mm | 180 N/mm | 80mm | 120 mm | -20/60℃ | Sanding, Inclined conveying |
50P22-16/9A | Green | 5.0mm | 3.5mm | Wavy super grip | 2 plies | 4.7Kg/㎡ | 10N/mm | 180 N/mm | 80mm | 120 mm | -20/60℃ | Sanding, Inclined conveying |
60P22-46/14A | Grey | 6.0mm | 1.8mm | Fishbone | 2 plies | 5.9Kg/㎡ | 10N/mm | 180 N/mm | 80mm | 120 mm | -20/60℃ | Wood |
20P25-14A | green | 2.0mm | 0.5mm | Smooth | 2 plies | 2.4kg/m2 | 8N/mm | 150 N/mm | 40mm | 60 mm | -15/80℃ | plane Conveying |
20P25-34/0A | Black | 2.0mm | 0.5mm | Matt | 2 plies | 2.4Kg/㎡ | 8N/mm | 150 N/mm | 40mm | 60 mm | -15/80℃ | packaging |
20P25-74/0A | Petrol | 2.0mm | 0.5mm | Matt | 2 plies | 2.4Kg/㎡ | 8N/mm | 150 N/mm | 40mm | 60 mm | - 15/80℃ | general Coneying |
30P22-11 | Green | 3.0mm | 0.7/0.8mm | Smooth/ Diamond | 2 plies | 3.6Kg/㎡ | 10N/mm | 180 N/mm | 100mm | 120 mm | -15/80℃ | wooden and food |
30P25-15A | Green | 3.0mm | 1.2mm | Smooth | 2 plies | 3.6Kg/㎡ | 8N/mm | 150 N/mm | 60mm | 80mm | -15/80℃ | Forming machine |
30P25-75A | Petrol | 3.0mm | 1.0mm | Smooth | 2 plies | 3.6Kg/㎡ | 8N/mm | 150 N/mm | 60mm | 80mm | -15/80℃ | Forming machine |
40P32-14A | Green | 4.0mm | 1.0mm | Smooth | 3 plies | 4.8Kg/㎡ | 15N/mm | 270 N/mm | 80mm | 100mm | -15/80℃ | Forming machine,Silo |
60P39-76 | Petrol | 6.0mm | 2.0mm | Smooth | 3 plies | 7.2Kg/㎡ | 50N/mm | 750N/mm | 300mm | 400mm | -15/80℃ | pre-pressing |
