INDUSTRY APPLICATION

Stone & Ceramics

INTRODUCTION

Tianjin Uyang Belting Co., Ltd.

UYANG BELTING conveyor belts used in the ceramics and stone industries are characterized by their high abrasion resistance, resistance to cutting, and extremely high tensile strength, with strict requirements for surface flatness. They undergo rigorous testing from material selection to production to the final product. These belts offer a variety of surface patterns to choose from and are widely utilized in marble and ceramic production lines.

type	color	Thickness	covering thickness	pattern	Number of plies	weight	Effective pull at 1% elongation (N/mm)	Min diameter (mm)	working temperature (℃)	Application：
70P39-28/15	White	7.0mm	2.0/1.0mm	Smooth	3 plies	8.4Kg/㎡	50N/mm	350mm	-15/80℃	Material Conveying
70P39-76/4	Petrol	7.0mm	2.0mm	Round nipple	3 plies	8.0Kg/㎡	50N/mm	350mm	-15/80℃	Stone & Ceramics
70P39-76/25	Petrol	7.0mm	2.0mm	Low grip	3 plies	8.2Kg/㎡	50N/mm	350mm	-15/80℃	Stone & Ceramics polishing
90P32-36/13	Black	9.0mm	6.0mm	Square	3 plies	8.0Kg/㎡	13N/mm	120mm	-15/80℃	wood
90P39-78/15	Petrol	9.0mm	2.0/2.0mm	Small golf	3 plies	10.8Kg/㎡	70N/mm	450mm	-10/80℃
90P39-79/15		9.0mm			3 plies		50N/mm	400mm	-15/80℃	stone pressing
90P49-76	Petrol	9.0mm	2.0mm	Smooth	4 plies	10.8Kg/㎡	70N/mm	450mm	-15/80℃	pressing
90P49-76/4	Petrol	9.0mm	1.9mm	Round nipple	4 plies	9.7Kg/㎡	70N/mm	450mm	-15/80℃	polishing
90P49-76/25	Petrol	9.0mm	2.5mm	Low grip	4 plies	10.6Kg/㎡	50N/mm	450mm	-15/80℃	polishing
90P49-86/49	Blue	9.0mm	2.5mm	Y pattern	4 plies	10.8Kg/㎡	70N/mm	400mm	-10/80℃	Thicknessing and polishing
110P39-76/23	Petrol	11.0mm	6.8mm	Tooth (one direction)	3 plies	8.4Kg/㎡	50N/mm	350mm	-15/80℃
110P39-76/34	Petrol	11.0mm	6.8mm	Tooth (two-direction)	3 plies	8.4Kg/㎡	50N/mm	350mm	-15/80℃	polishing
115P39-76/23	Petrol	11.5mm	7.3mm	Tooth (one direction)	3 plies	8.5Kg/㎡	50N/mm	350mm	-20/60℃
120P42-74/0H(1)RED	RED	12.0mm	6.0mm	Matt	4 plies	14.4Kg/㎡	25N/mm	200mm	-10/90℃	cutting
125P49-76/23	Petrol	12.5mm	7.3mm	Tooth (one direction)	4 plies	10.1Kg/㎡	70N/mm	450mm	-20/60℃
125P49-76/34	Petrol	12.5mm	7.3mm	Tooth (two-direction)	4 plies	10.1Kg/㎡	70N/mm	450mm	-15/80℃
130P49-76/23	Petrol	13.0mm	6.0mm	Tooth (one direction)	4 plies	10.8Kg/㎡	70N/mm	450mm	-15/80℃	polishing
130P49-76/34	Petrol	13.0mm	6.5mm	Tooth (two-direction)	4 plies	11.1Kg/㎡	70N/mm	450mm	-15/80℃	Stone & Ceramics
40P33-27G	White	4.0mm	1.0mm	Fabric	3 plies	4.8Kg/㎡	10N/mm	140mm	-15/80℃	Automotive & Tyre
130P49-86/34	Blue	13.0mm	6.5mm	Tooth (two-direction)	4 plies	11.1Kg/㎡	70N/mm	450mm	-15/80℃	Stone & Ceramics Material Conveying
50P32-76/4	Petrol	5.0mm	2.0mm	Round nipple	3 plies	5.6Kg/㎡	18N/mm	150mm	-15/80℃	Stone & Ceramics
