Belts coated with silicone provide:

1. Excellent release properties

2. High temperature resistance

3. Hydrolysis resistance

4. High chemical resistance

The use of a silicone coating must always respect the mechanical limits of this elastomeric material, which is suspect to scratch and wear and can thus lose its properties in rough applications.

Uyang Belting has two ranges of silicone-coated belts to meet different application requirements:

1. General purpose silicone belts feature a silicone with a super-adhesive surface and regular abrasion resistance and durability.

2. Wear-resistant silicone belts use a high-grade silicone rubber. Thus it offers excellent surface quality. Good wear resistance and durability are combined with temperature resistance up to 180 °C / 356 °F

Our silicone conveyor belts consist of a rubber coating and two layers of polyester. The advantages of silicone are obvious. It is resistant to many chemicals, greases and oils. A further big advantage of silicone is its exceptional anti-adhesive effect.

Silicone is the ideal material for the coating of a wide range of conveyor belt fabrics. Because they are customized, versatile easy to process and also they are robust. What’s more, they guarantee durability. Before we make a conveyor belt we consider a range of features. For instance, anti-slip and release features, durability, temperature and environmental resistance and safety and regulatory requirements.

CONSTRUCTION

•  2-plies Silicone-impregnated Polyester (PES)

•  Topside: Silicone, White color, 0.8mm

•  Middle Layer : Silicone-impregnated, PES, 1.1mm

•  Bottomside: cotton fabric, 1.1mm

•  TEMPERATURE CONTINUOUS -30C to +180C.

Special Features : Approved by FDA, High Temperature, Non-stick, low coefficient of friction on top side.

Applications:

· Food & Pharmaceutical Industries

· Biscuit Industries

· Chocolate Industries,

· Meet and Fish Industries

· Automotive Industries

· Fertilizer Industries

· Soap and Detergent Industries

· Wood Industries

FAQ:

1. What thickness can you produce for silicone belts?

Answer: Usually from 2mm to 4mm.

2.  *What's max temperature can be resistant?

Answer: the max temperature resistant is 250 C.

3.  *How to joint the belt?

Answer:The way to joint the silicone belt is Overlap.

We can provide Preparing jointing belts for customers, the spareparts like glue, film. In this case, customers can joint the belts at site for end users.
